Super Turbo Muffler WRX STI Explanation of the product Application chart

WRX STI CBA-VAB
Code No. 31029-AF013







Cert. No. JQR40154205

Vehicle WRX STI
Model VAB
Engine EJ20(TURBO)
Model Year 14/08 -
Shape of muffler Ti-1 (Titan)
(Super Turbo Muffler)
Main material S304(*2)
Diameter of tip 90×2 L&R
Diameter of center pipe 75-60-54(*3)
Close noise level Stock 78
HKS 85
About road clearance(*4) Clearance 125mm
Portion of the kit Center pipe
Remarks
Product Weight 26.1kg





Remarks

86db: with 33005-AF014



About HKS muffler

*1: About silencer shell type of Silent Hi-Power
TYPE-S/Oval silencer for noise reduction.
TYPE-H/Round silencer for performance.

*2: Main material in the component figure.

: SUS304/High quality stainless steel.
: SUH409/Stainless steel commonly used for stock exhaust.

*3: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.

*4: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.

Caution: Hook, bracket, stay may be changed without prior notice.

★ Exhaust noise level at idle.
