Super Turbo Muffler
LEVORG
LEVORG DBA-VM4

Code No. 31029-AF010

















Cert. No. JQR40144187
Vehicle LEVORG
Model VM4
Engine FB16(TURBO)
Model Year 14/06 - 20/10
Shape of muffler SSR
(Super Turbo Muffler)
Main material S304
Diameter of tip 110 L&R
Diameter of center pipe 60-50 x 2 (*1)
Close noise level Stock 72
HKS 72
About road clearance(*2) Clearance 140mm
Portion of the kit Center pipe
Remarks
Product Weight
Remarks

Includes Center Pipe. * Silver color exhaust tip. (not burnt blue)



About HKS muffler

*1: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.

*2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.

Caution: Hook, bracket, stay may be changed without prior notice.

★ Exhaust noise level at idle.
