Code No. 31021-AT006
New Black Exhaust Tail Tip
Adopts a newly designed tail tip that has undergone ion plating with excellent corrosion resistance and weather resistance. Black color and HKS laser engraved.
Combine both comfortability and sport sound
Providing comfortability at usual use and a distinctive sporty sound during acceleration.
Comfortable aftermarket exhaust
In the daily speed range, the exhaust sound volume is not just a big but also comfortable. You can enjoy dry sporty sound by stepping on a gas pedal.
| Cert. No. | JQR20202129 |
|---|
| Vehicle | GR YARIS |
|---|---|
| Model | GXPA16 |
| Engine | G16E-GTS |
| Model Year | 20/09 - 24/03 |
| Shape of muffler | SSR (LEGAMAX Premium) | |
|---|---|---|
| Main material | S304 | |
| Diameter of tip | 101.6 L&R | |
| Diameter of center pipe | φ70 – φ54 x 2 (*1) | |
| Close noise level | Stock | 79 |
| HKS | 84 | |
| About road clearance(*2) | Clearance | 145mm |
| Portion of the kit | Main Pipe | |
| Remarks | ||
| Product Weight | 14.0kg | |
Remarks
• Not compatible with RS (1.5L FF) grade.
• RC-grade vehicle with standard 17-inch tires complies with Japanese car inspection regulations.
• Not compatible with a vehicle with GR rear bumper spoiler.
• GRMN YARIS does not comply with Japanese car inspection regulations.
• Not compatible with the model made after March 2024.
About HKS muffler
*1: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.
*2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.
Caution: Hook, bracket, stay may be changed without prior notice.
★ Exhaust noise level at idle.
