Code No. 31021-AH005
Revolutionary Exhaust System Unleashes Peak Performance While Slashing Pressure
Turbocharge Your Ride
Unlock -30% Exhaust Pressure with Sleek φ75 Full Straight Design and Φ119 Titanium Tail with HKS logo.
Rev Up the Thrill
Enjoy a Crystal-Clear Sporty Sound Experience with Innovative Valveless Design and Cabin Comfort.
Cert. No. | JQR30233117 |
---|
Vehicle | CIVIC TYPE R |
---|---|
Model | FL5 |
Engine | K20C |
Model Year | 22/09 - |
Shape of muffler | Ti (Titan)
(LEGAMAX Sports) |
|
---|---|---|
Main material | S3/S4L | |
Diameter of tip | 119 | |
Diameter of center pipe | 74.7 → 60.5 × 2 (*1) | |
Close noise level | Stock | 84 |
HKS | 93 | |
About road clearance(*2) | Clearance | 125mm |
Portion of the kit | Factory front under panel | |
Remarks | ||
Product Weight | 18.5kg |
A dedicated actuator for factory valve motor included
Stock pipe diameter: φ60 → φ50×2 (when the valve is closed), φ60×1 (when the valve is open).
LMS pipe diameter: φ74.7 → φ60.5×2.
Acutuator
Actuator + Stock Valve Moter
*1: About center pipe
Diameter of center pipe is the portion that has the largest diameter. (Excluding silencer and tip.) It is the condition with stock suspension.
*2: Minimum road clearance between HKS muffler (Any parts included in the kit) and road surface. Therefore, it may be different from actual road clearance of the vehicle.
The data is basically the condition with stock suspension. However, please understand that some items have data with low down spring or ride height adjustable suspension kit.
Caution: Hook, bracket, stay may be changed without prior notice.
★ Exhaust noise level at idle.
