Limited Edition
for WRX STI (VAB)
参考出品/Reference Exhibit
スーパーターボマフラー W-Tail をベースとしたリミテッドエディション!
Super Turbo Muffler Limited Edition Designed Based on W-tail Model!

2タイプのスーパーターボマフラーのリミテッドエディション!
2 types of Super Turbo Muffler Limited Edition!
Black Edition
ブラックテールがWRXのリアビューを引き締め、チタンブルーのヒートグラデーションテールとは一味違った大人なスーパーターボマフラーに仕上げました!
The black exhaust tips accentuate the rear view of WRX with mature appearance and differentiate from the titanium blue gradation tips.
Titanium Edition
材質をチタンとすることで、従来品の性能をスポイルさせることなく、SUS品26.1㎏に対し13.4㎏と約48%減の大幅な軽量化!!マフラーの理想型を追求した一品に仕上げました!
Titanium material enables to reduce the total weight approximately by 48% from the SUS made exhaust system without spoiling the original performance!! This is the ideal type of the exhaust system!
Black Edition


Titanium Edition


for WRX STI (VAB)
本体価格:¥198,000
マフラーの理想型を追求
Pursuit of the Ideal Exhaust System

パワーが出るだけ…静かなだけ…じゃない!
快適な車内を残したまま、ひとたびアクセルを踏み込めば乾いたスポーツサウンドを感じていただけます!
φ75絞り無しストレート構造だから出来る圧倒的な低排圧と静かで快適な車内を両立!
Once stepping on the accelerator pedal, dry sporty exhaust sound is heard throughout the comfortable vehicle's interior.
φ75 straight structure generates lowest exhaust pressure possible whilst maintaining comfort within the interior


型式 | CBA-VAB | |
---|---|---|
エンジン型式 | EJ20 | |
年式 | 2014/9~ | |
認証番号 | JQR4054205 FA20t | |
主要材質 | SUS304 | |
テール外径 | φ90×12 | |
パイプ径 | φ74.7→φ60.5×2→φ54×4 | |
近接排気音 (アイドリング音量) |
ノーマル | 78dB(60dB) |
HKS | 85dB(70dB) | |
製品装着最低地上高 | 125mm(中間パイプ) | |
排気管最低地上高 (部位) |
125mm(中間パイプ) | |
備考 |
