CYLINDER HEAD COMPONENTS

V CAM System (Version Up)

Option parts for upgrade from "V CAM SYSTEM STEP1" to "STEP2".

Version upgrade from STEP1 to STEP2.

[Items Required to upgrade]

①22002-AN036 (Cam Shaft 264°)
②22999-AN005 (Unit Assy Variable range 50°)
③22999-AN006 (Cam Cover Gasket)

* Item recommended for replacing when upgrading the V Cam System.

22999-AK001 Overhaul Set

* HKS Forged Piston Kit is required to use with the V-Cam System Step2.

CAMSHAFT
Engine INTAKE SIDE Remarks
Duration Valve Lift Valve Timing Code No. Price
RB26DETT 264° 8.7mm 75°-125° 22002-AN036   Includes only the V CAM SYSTEM STEP2 Camshaft.
Requires HKS Forged Piston Kit.
RB26DETT Vcam SYSTEM Unit Assy 50°
Code No. Price Remarks
22999-AN005
RB26DETT Vcam SYSTEM Cam Cover Gasket
Code No. Price Remarks
22999-AN006   RB26 Camshaft Cover Gasket

This kit includes O-rings and bolts to overhaul the V Cam System.
Useful for overhauling the V Cam System.

Complete Parts
 O-rings for Joint Pipe
(4 pcs)
Thickness:φ1.5
/ I.D.: φ5.5
 O-ring for Adapter Connector
(1 pc)
Thickness:φ1.9
/ I.D.:φ13.0
 O-ring for Oil Control Valve
(1 pc)
Thickness:φ1.9
/ I.D.:φ16.8
 O-ring for Cam Angle Sensor
(1 pc)
Thickness:φ2.4
/ I.D.:φ13.8
Variable V/T Unit Cover
Plate Bolts (3 pcs)
M5 x 10
