Suspension with high comfortability for street driving has arrived for JIMNY SIERRA. Enjoy driving wherever you want with light drive feeling and a solid and stable look. |
|
![]() |
|
for JIMNYSIERRA (JB74W)
|
![]() |
Vehicle | Model | Engine | Year | Spring Rate [N/mm (kgf/mm)] |
Spring | Vehicle's height Default (High-Low) |
Code No. | Upper Mount | Upper mount Assy before shipment |
Spring Rate Change |
Remarks |
---|---|---|---|---|---|---|---|---|---|---|---|
JIMNY SIERRA | JB74W | K15BA | 18/7~ | F=42(4.3) R=39(4) | Special shape | F=-30 R=-35 | 80270-AS002 | F=Stock Rubber R=Rubber |
Impossible | F=Impossible R=Impossible |
Equipped with damping force adjustment 30 levels. Please use a stock bump rubber. |
