METAL CATALYZER
BRZ
BRZ ZC6

Code No. 33005-AT008





SUPER MANIFOLD with CATALYZER R-SPEC for ZN6/ZC6









The Exhaust Manifold is a crucial part for 86 and BRZ to improve the engine power output. The stock exhaust manifold is equipped with the catalyst, and cannot bring the best out of the output performance of the engine due to an exhaust resistance from this catalyst. HKS' exhaust manifold improves the output performance while meeting the vehicle emissions control in Japan by employing the compact catalyst which has lower exhaust resistance and an improved purifying effect.











■Features

The exhaust manifold employs the 4-2-1 equal length (explodes at equal interval) layout designs to emphasize its performance. A specially designed compact catalyst is meeting the vehicle emissions control in Japan while supporting the precious metal catalyst, which highly affects the purification performance of the exhaust gas. SUPER MANIFOLD with CATALYZER R-SPEC, which is for the early model, has been remade to match the late model! It is a great combination of using with GT SUPERCHARGER SYSTEM GTS7040L, and it brings out the high performance.











Vehicle Classification Model Engine Model Year Pipe Size Code No. Manual Remarks
BRZ ZC6 FA20 16/08 -19/03 Φ42.7-50.8-60 33005-AT008 [R-SPEC] For MT, late model. A front pipe set includes the 1st catalyst which was changed to the straight layout manifold and the 2nd catalyst which is replaced with the metal catalyzer. For meeting the vehicle noise regulations in Japan, the combination use of the stock muffler is necessary. Weight: HKS 12.2kg, Stock 14.8kg. Compatible with 4BA-ZN6.
