Dynamic lifted-up style with ensuring comfort in street driving.

HIPERMAX G+　LIFT UP

for JIMNY SIERRA (JB74W)

＜Product Basic Structure＞
●Single Tube Damper Assembly
●Lift Up
※The stock upper mounts are used.

■Features

• Lifting up the vehicle height 20 to 25 mm higher makes JIMNY SIERRA more stylish and it also set to a good match with the high rate spring.
• Reduce excessive body roll or yawing due to the strong damping force made by the single-tube shock absorber. It also provides a comfortable ride on the paved road. Significantly improved the stability when turning by reducing the degree of body roll and speed.
• Offers 30 steps of adjustable damping force that can be selected for your preferable ride.

■Kit Parts

Vehicle	Model	Engine	Model Year	Series	Full Kit Spring Rate F/R	Free Height	Damping Force Piston Speed 0.1m/sec Damping Force N		Vehicle Height (Highest - Lowest)		Code No.	Manual	Remarks
							F: Rebound/Compression	R: Rebound/Compression
JIMNY SIERRA	JB74W	K15B	18/07 -	G+	F=45(4.6)/R=39(4)	Special/Special	471/422	353/265	+25	+20	80270-AS004		Make to order item Equipped with damping force adjustment 30 levels. Please use a stock bump rubber.
