HKS

PRODUCTSUSPENSION

HOME  >  PRODUCT  >  SUSPENSION  >  HIPERMAX S-style C

HIPERMAX SERIES

HIPERMAX S-style C

  • Single Tube
  • Fixed Damping
  • Adjustable
    Shock Body
  • Special Oil
  • PNE Coating
  • Preload Valve
    System
  • MAX 4 Piston
  • Invented Type
    *1
  • Rubber
    Upper Mount
  • Specification
    Changes Available
  • Overhaul
    Available

*1 MacPherson Strut Only

Masterpiece of HKS "S-style" series!
For the Best & Firm Ride!!

HKS S-style C was designed for those who want to enjoy the driving with family or friends with customizing cars.
HKS S-style C can provide comfortable long distance driving even with a customized car.

* Discontinued.

  • single tube
  • Fixed Damping
  • Adjustable
    Shock Body
  • special oil
  • PNE coating
  • Preload Valve
    System
  • MAX 4 Piston
  • Invented Type
    *1
  • Rubber
    Upper Mount
  • Specification
    Changes Available
  • Overhaul
    Available

*1 MacPherson Strut Only

HKS suspension is single tube! Applicaiton Chart


Overhaul
Single tube Design
A mono-tube suspension structure was utilized for high durability, and comfort even in the harshest driving conditions.
Inverted Strut Type
Strut type dampers use inverted design for added structural rigidity. High rigidity is maintained by supporting the large bending force with a thick pipe; it is retained even when wearing large tires that increase unsprung weight.
PNE Coating
PNE Coating's corrosion resistance is 5 times as much as the galvanization's. This coating can protect against rust, and its smooth surface requires less force to adjust the ride height than conventional dampers.
High Grade Damper Oil
Sports damper oil used for MAX IV series is chosen as a damper oil; it maintains stable damping force and restrains heat sagging caused during high-load driving and/or summer.
PVS(Pre-load Valve System) & M4P(MAX IV Piston)
PVS (Pre-load Valve System) allows dampening force generation at low speed whilst maintaining suitable force at high speed. An even larger effect is achieved when combined with M4P. As used in MAX IV series, M4P is able to balance dampening force generation at low piston speeds whilst maintain control at high speed.
New Design Bump Rubber
From compacts to mini vans, all new range of bump rubbers have been created to suit various vehicles and driving conditions to help reduce harshness from bottoming out.
Strengthened Rubber Upper Mount
Strengthened rubber upper mount for comfort during street driving.
Silent Tube & Spring Insulator
"Silent Tube" & "Spring Insulator" are equipped on springs to suppress unwanted noise.
Aluminum Lock Nut & Ride Height Adjuster
The anti-rust and corrosion characteristics for enhanced durability are featured. Using these can trim weight below the spring.

HKS warrants the suspension product for a period of one (1) year from the date of original purchase for overseas markets.
