HKS



CIVIC TYPE-R / CIVIC
CUSTOMIZED PARTS

HKS actively develops new and diverse HONDA CIVIC products for the markets all over the world.

TYPE-R [FK8]

2 Exhaust Models for FK8 CIVIC TYPE R

  • LEGAMAX Premium

    LEGAMAX Premium CIVIC TYPE-R(FK8)

  • HiPower SPEC-L

    Hi-Power SPEC-L CIVIC TYPE-R(FK8)

PARTS LINEUP

HKS parts for HONDA CIVIC TYPE-R [FK8]

Code No. Product Engine Model Remark
EXHAUST
31021-BH003		 LEGAMAX Premium K20C
TURBO		 HB Compatible with 6BA-FK8.
31019-AH106		 Hi-Power SPEC-L II K20C
TURBO		 HB Tail cover size:φ94 L=48, 2 pcs required.
Including Main and Mid pipe.
Compatible with 6BA-FK8.
31019-AH006		 Hi-Power SPEC-L K20C
TURBO		 HB * Discontinued.
Compliant with Japanese regulation
33006-KH001		 DOWNPIPE K20C
TURBO		 HB
SUSPENSION
80310-AH003		 HIPERMAX R K20C
TURBO		 HB * Error is displayed when the stock dampers are removed.
An optional canceller is required to avoid the error display.
80300-AH012P		 HIPERMAX S
Pillow ball spherical bearing type
(Front)		 K20C
TURBO		 HB An error message will be displayed when the OEM suspension is removed.
The error display can be avoided by purchasing a canceller separately.
(Code No. 45012-AH002: SEC II Type-H)
80250-AH003		 HIPERMAX MAX IV SP K20C
TURBO		 HB * Discontinued.
* CEL comes on if the stock suspension is removed.
CEL can be canceled by an error canceller that is available separately.
80250-AH003C		 HIPERMAX MAX IV SP with SEC K20C
TURBO		 HB * Discontinued.
With SEC.
45012-AH002		 SEC II(Suspension Error Canceler II) Type H K20C
TURBO		 HB There are no plans to sell the suspension and
error canceller as a kit for FK8. Please purchase separately.
45012-AH001		 SEC(Suspension Error Canceler) Type H K20C
TURBO		 HB * Discontinued.
HKS Suspension Option Part
INTAKE
70020-AH109		 RACING SUCTION KIT (AFR) K20C
TURBO		 HB Includes AFR.
6BA-FK8 not confirmed.
70020-AH110		 RACING SUCTION KIT K20C
TURBO		 HB Doesn't include AFR.
Requires ECU recalibration.
6BA-FK8 not confirmed.
70026-AH006		 Cold Air Intake Full Kit K20C
TURBO		 HB Racing Suction + Dry Carbone Intake Box + AFR
6BA-FK8 not confirmed.
70026-AH007		 Cold Air Intake Full Kit K20C
TURBO		 HB Racing Suction + Dry Carbone Intake Box
6BA-FK8 not confirmed.
70026-AH008		 Cold Air Intake Box K20C
TURBO		 HB Dry Carbone Intake Box
For 70020-AH109 or 70020-AH110
6BA-FK8 not confirmed.
BLOW OFF
71008-KH009B		 SUPER SQV IV Black Editon K20C
TURBO		 HB Compatible with a vehicle with Intercooler Piping Kit (13002-AH001).
71008-AH009		 SUPER SQV Vehicle Specific Kit K20C
TURBO		 HB Compatible with a vehicle with Intercooler Piping Kit (13002-AH001)
71002-AH003		 SUCTION RETURN KIT K20C
TURBO		 HB * Compatible with the combination use with the Racing Suction or Cold Air Intake.
* Compatibility for 6BA-FK8 is not confirmed.
ELECTRONICS
42018-AH002		 POWER EDITOR K20C
TURBO		 HB Compatible with 6MT model. TBA
6BA-FK8 not confirmed.
44009-AK001		 OB-LINK K20C
TURBO		 HB
COOLING
13001-AH004		 INTERCOOLER Vehicle Specific Kit K20C
TURBO		 HB ・Installation requires approx. 4 hours.
・I/C IN & OUT pipes included.
13001-AH005		 INTERCOOLER Vehicle Specific Kit
(I/C core only)		 K20C
TURBO		 HB ・Installation requires approx. 3.5 hours.
・I/C core only.
・For a vehicle with 13002-AH001 PPK for FK8
13002-AH001		 INTERCOOLER PIPING Vehicle Specific Kit K20C
TURBO		 HB Required Installation Time: 1 hr.
Removal of under panel is required.
15004-AH004		 OIL COOLER Vehicle Specific Kit K20C
TURBO		 HB Standard Installation Time: 4 hours
Aluminum air guide is included.
ENGINE
24996-AK046		 FINE TUNE V-BELT/6PK1710 K20C
TURBO		 HB ・For CIVIC TYPE-R(FK8)
・For a water pump, A/C, and alternator
OIL & PLUG
52001-AK071		 Racing Pro -5W-30 20L K20C
TURBO		 HB High Grade
Nomal viscosity:
ULTRA LEO SAE 0W-20
52001-AK112		 SUPER OIL Premium 0W-20 SN 4L K20C
TURBO		 HB STD
Nomal viscosity:
ULTRA LEO SAE 0W-20
52001-AK108		 SUPER OIL Premium 0W-25 4L K20C
TURBO		 HB STD
Nomal viscosity:
ULTRA LEO SAE 0W-20
52009-AK005		 OIL FILTER (φ68-M20) TYPE-1 K20C
TURBO		 HB
50003-MR45HLZ		 SUPER FIRE RACING MR45HLZ K20C
TURBO		 HB 4 plugs required.
Stock: #9 NGK ILZKAR8H8S
COOLANT
52008-AK002		 SUPER Coolant Racing Pro K20C
TURBO		 HB Racing Type
Volume: 5L
52008-AK003		 SUPER Coolant Sport K20C
TURBO		 HB Sports Type
Volume: 5L
52008-AK004		 SUPER Coolant Touring K20C
TURBO		 HB Multi‐purpose Type
Volume: 5L
OTHERS
70027-AH001		 NANO CABIN FILTER K20C
TURBO		 HB

SEDAN/COUPE/HATCHBACK [FC1/FC3/FK7]

PARTS LINEUP

HKS parts for HONDA CIVIC SEDAN/COUPE/HATCHBACK [FC1/FC3/FK7]

Code No. Product Engine Model Remark
EXHAUST
31019-AH108		 Hi-Power SPEC-L II L15C HB Tail cover size:φ94 L=118 A, OPTION Tail Requirement (pcs):2
31019-AH107		 Hi-Power SPEC-L II L15C HB * Discontinued.
Tail cover size:φ94 L=118 A, OPTION Tail Requirement (pcs):2
Compatible with DBA-FK7 (2017-2019) with MUGEN rear under spoiler.
Not compatible with 6BA-FK7 made after 2020.
Overseas Model (US Market is not included)
31013-ZH001		 LEGAL Muffler L15B SEDAN For the models available in Southeast Asia and China
31013-ZH002 LEGAL Muffler L15B SEDAN W/O Silencer / For the models available in Southeast Asia and China
31013-ZH003 LEGAL Muffler L15B HB For the model available in Southeast Asia
In development LEGAL Muffler Carbon Tail Ver. L15B SEDAN For the models available in Southeast Asia and China
In development LEGAL Muffler Carbon Tail Ver. L15C HB For the model available in Southeast Asia
32008-ZH005 LEGAL Muffler NA R18Z NA SEDAN For the model available in Southeast Asia
Overseas Model (For US Market)
31021-BH004		 LEGAMAX Premium L15B SEDAN For the model available in the U.S.
31021-AH004		 LEGAMAX Premium for FK7 L15C HB ※This product was previously released as 31021-BH002
Since fitment to JDM model was confirmed, the part number was changed to 31021-AH004.
Also, this product is designed based on JDM and USDM models.
Please confirm the model available in your country before purchase.
Compatible with DBA-FK7 (2017-2019) with MUGEN rear under spoiler.
31021-BH001		 LEGAMAX Premium L15B COUPE For the model available in the U.S.
31006-BH002		 Hi-Power Muffler Si L15B SEDAN For Si model / For the model available in the U.S. In development
31006-BH001		 Hi-Power Muffler Si L15B COUPE For Si model / For the model available in the U.S.
SUSPENSION
80300-KH001C		 HIPERMAX S
FULL CANCELLER KIT		 L15B HB For FC1
80300-KH001C		 HIPERMAX S
FULL CANCELLER KIT		 L15B HB For FC3
80300-KH001		 HIPERMAX S L15B HB For FC1
80300-KH001		 HIPERMAX S L15B HB For FC3
80300-AH009		 HIPERMAX S L15C HB
80230-AH008		 HIPERMAX MAX IV GT
Front knuckle's insertion dia.:φ50.5		 L15B SEDAN/
COUPE/HB		 US-SEDAN/COUPE, Thailand-SEDAN/HB
80230-KH001		 HIPERMAX MAX IV GT
for US Si Model Front knuckle's insertion dia.:φ53.8		 L15B SEDAN/
COUPE		 USA Si SEDAN/COUPE
80250-AH004		 HIPERMAX MAX IV SP L15C HB * Discontinued.
Only applicable with a vehicle with front knuckle's insertion diameter 52mm.
Please check the diameter with an application chart before purchase
80230-AH009		 HIPERMAX MAX IV GT
Front knuckle's insertion dia.:φ52		 L15B SEDAN/HB * Discontinued.
USA-HB, China-SEDAN, Japan-SEDAN
80230-KH001C		 HIPERMAX MAX IV GT with SEC
for US Si Model Front knuckle's insertion dia.:φ53.8		 L15B SEDAN/
COUPE		 * Discontinued.
USA Si SEDAN/COUPE
45012-AH002		 SEC II (Suspension Error Canceler II)
Type H		 L15B SEDAN/
COUPE		 USDM Model
A suspension and error canceller kit is available
for FC1 and FC3. (Code No. 80300-KH001C)
45012-AH001		 SEC (Suspension Error Canceler)
Type H		 L15B SEDAN/
COUPE		 USDM Model
HKS Suspension Option Part
INTAKE
70020-AH111		 RACING SUCTION KIT L15B
L15C		 SEDAN/HB
70017-AH118		 SUPER AIR FILTER L15B
L15C		 SEDAN/HB Reuse stock rubber packing.
ELECTRONICS
42018-AH001		 POWER EDITOR L15C HB
44009-AK001		 OB-LINK L15C HB For FK7
BLOW OFF
71008-AH010		 SUPER SQV　Vehicle Specific Kit L15B
L15C		 SEDAN
/HB		 Compatible with MT,CVT, includes recirculation tube
71008-AH011		 SUPER SQV　Vehicle Specific Kit L15B
L15C		 SEDAN
/HB		 Compatible with MT,CVT, doesn't include recirculation
COOLING
13001-AH006		 INTERCOOLER KIT (R type) L15C HB Compatible with 6MT & CVT.
Compatibility with 6BA-FK7 has not confirmed.
ENGINE
24996-AK047		 FINE TUNE V-BELT/7PK1710 L15C HB ・For CIVIC HATCHBACK(FK7) ※For CIVIC SEDAN(FC1), compatibility is not confirmed.(Genuine P/N 31110-5AG-Z01)
・For a water pump, A/C, and alternator
OIL & PLUG
52001-AK071		 Racing Pro -5W-30 20L L15B SEDAN/
COUPE/HB		 High Grade
Nomal viscosity:
ULTRA LEO SAE 0W-20
52001-AK112		 SUPER OIL Premium 0W-20 SN 4L L15B SEDAN/
COUPE/HB		 STD
Nomal viscosity:
ULTRA LEO SAE 0W-20
52001-AK108		 SUPER OIL Premium 0W-25 4L L15B SEDAN/
COUPE/HB		 STD
Nomal viscosity:
ULTRA LEO SAE 0W-20
52009-AK005		 OIL FILTER (φ68-M20) TYPE-1 L15B SEDAN/
COUPE/HB
COOLANT
52008-AK002		 SUPER Coolant Racing Pro L15B SEDAN/
COUPE/HB		 Racing Type
Volume: 5L
52008-AK003		 SUPER Coolant Sport L15B SEDAN/
COUPE/HB		 Sports Type
Volume: 5L
52008-AK004		 SUPER Coolant Touring L15B SEDAN/
COUPE/HB		 Multi‐purpose Type
Volume: 5L
OTHERS
70027-AH001		 NANO CABIN FILTER L15B SEDAN/
COUPE/HB
15009-AK004		 RADIATOR CAP L15B SEDAN/
COUPE/HB		 108kPa (1.1kgf/cm2)

▲
